YY-2D Underground Diesel Loader Underground Electric Scooptram
Features:
1.YY-2D scooptram (underground loader) adopts Germany Deutz F6L912 Engine, driving system adopts American DANA Torque converter and gearbox, which is of easy operation and smooth running.
2.The braking system adopts hydraulic double pipe working system, and equipped with multi-disk wet braker, self-developed anti-skid differential mechanism of NO-SPIN, performs rather well even in bad conditions like harsh, high water saturation environments and muddy tunnel.
3.The main components of the hydraulic system adopts well-known manufacturers ' products both at home and abroad, manual operating diverter valve control the steering. Using pilot valve equipped with ergonomics handle to control the bucket arm lifting and bucket tilting.
4.Elaborate designed and manufactured electric scooptram has beautiful shape and high work efficiency. Mainly used for mine, loading and transporting the loose material which is left after bursting. It can also be used for tunnel engineering such as underground railway, highway and water conservancy, especially suitable for workingplane of poor work conditions , narrow working platform, low and muddy working face.
Main Technical Parameters:
| Engine: | DEUTZ F6L912 63KW |
| Transmission System: | DANA RT20326 |
| Braking System: | Working Braking, Parking Brake |
| Maximum Lifting Height: | 3740mm |
| Total Weight: | 12T |
| Maximum Traction: | 100KN |
| Hydraulic Tank Capacity: | 156L |
| Steering Angle: | ±33° |
| Torque Converter: | DANA C272 |
| Drive Axle Type: | NO-SPIN |
| Bucket Capacity: | 2 m3 |
| Min. Ground Clearance: | 250mm |
| Gradeability: | 16° |
| Max. Shovel Force: | 80KN |
| Running Speed: | 0-10km/h |
| Min. Turning Radius: | 5200mm |
| Max .Discharge Height: | 1600mm |
| Dimensions(Length* Width*Height): | 7300 * 1500 * 2050mm |
|
|
YY-2D Underground Diesel Loader Underground Electric Scooptram Images
|
